2013 Haas TL-3
Sold
2013 Haas TL-3
Location:Alberta, Canada
Description
12" 3 Jaw Manual Chuck
Tailstock
Quick Change Tool Post
Steady Rest
Manual Hand Wheels
Full Enclosure Doors
15" LCD Color Monitor
Memory Lock Key Switch
Intuitive Programming System
USB Port Interface
RS 232 Port Interface
Work Light
Coolant Tank & Pump
Set of Chuck Jaws
Wired 195-260V Electrics
**Machine Mfg. new in December of 2013, has been in storage since approximately 2018 and has ONLY about 1,000 hrs of use**
**Not currently under power, will need to have batteries replaced and be reinitialized**
Specifications
| Manufacturer | Haas |
| Model | TL-3 |
| Year | 2013 |
| Condition | Used |
| Stock Number | 118900 |
| Machine Control | Haas CNC Control |
| Chuck Size | 12" 3-Jaw Manual Chuck |
| Maximum Swing | 20" |
| Maximum Swing Over Cross Slide | 13" |
| Maximum Machining Diameter | 20" |
| Distance Between Centers | 60" |
| X-axis travel | 16" |
| Z-Axis Travel | 60" |
| Spindle Speeds | 1,800 RPM |
| Spindle Nose / Bore / Bar Capacity | A2-6" / 3.5" / 3.5" |
| Spindle Motor | 18 HP |
| Number of Tool Positions | Tool Post |
| Rapid Traverse Rates X/Z | 75 IPM / 150 IPM |
| Tailstock Bore Taper | #5 MT |
| Machine Dimensions LxWxH | 123" x 77" x 87" |
| Machine Weight | 7,624 lbs |
