2011 Haas VF-3SS w/ 5-Axis Trunnion Table

2011 Haas VF-3SS w/ 5-Axis Trunnion Table

Contact us for price

Location:Tennessee

orCall (863) 439-6066

Description

Haas 5-Axis Trunnion Table

24+1 Position Side Mounted Tool Changer

1,000 PSI Coolant Thru the Spindle

WIPS Renishaw Tool & Part Probe

Chip Conveyor

Spindle Orientation

Coordinate Rotation & Scaling

User Definable Macros

Haas Intuitive Programming System

Remote Jog Handle

Programmable Coolant Nozzle

Coolant Tank with Pump

Inline Direct Drive 12,000 RPM Spindle

USB Port Interface

RS 232C Port Interface for DNC Operation

All Available Manuals

Miscellaneous Tooling

**Ran Plastic**

New Spindle and Coupling Installed


Show All

Specifications

ManufacturerHaas
ModelVF-3SS w/ 5-Axis Trunnion Table
Year2011
ConditionUsed
Stock Number119690
Machine ControlHaas CNC Control
Table size48" x 18"
Max table load1,750 lbs
X axis travel40"
Y axis travel20"
Z axis travel25"
Spindle taperCAT #40
Spindle speed12,000 RPM
Spindle motor30 HP - Direct Drive
Spindle nose to table top4.2" - 29.2"
Number of tool positions24 + 1 Position Side Mount
Max tool weight12 lbs.
Rapid feed rate (x,y,z)1,400 IPM
Cutting feed rate0.1 - 833 IPM
Machine dimensions122" x 98" x 98.5"
Machine weight (approximately)12,500 lbs.
