2009 Haas SL-20T with Full C Axis Spindle Rotation, Milling, Tailstock, Chip Conveyor
2009 Haas SL-20T with Full C Axis Spindle Rotation, Milling, Tailstock, Chip Conveyor
$29,950 (USD)
Location:North Carolina
orCall (863) 439-6066
Description
Full C Axis Spindle Rotation
Live Milling Capability
Chip Conveyor - Belt Type
Tool Presetter
Programmable Hydraulic Tailstock
8" 3 Jaw Hydraulic Chuck
High Intensity Lighting
Spindle Orientation
Rigid Tapping
Coolant System with Tank & Pump
USB Port Interface
RS232 Port Interface
All Available Manuals
Tooling Includes (1) Axial and (1) Radial Live Tool Holder
Wired 195-260V Electrics
The collet chuck in the picture does not go with the machine
**ONLY 2,609 RUN TIME HOURS, CONSIDERABLY LESS SPINDLE HOURS**
**To Be Removed From a Community College Tech School in January 2025**
Specifications
Manufacturer | Haas |
Model | SL-20T with Milling |
Year | 2009 |
Condition | Used |
Stock Number | 119816 |
Machine Control | Haas CNC Control |
Chuck Size | 8" 3-Jaw Hydraulic Chuck |
Maximum Swing | 20" |
Maximum Swing Over Cross Slide | 11.75" |
Distance Between Centers | 22.5" |
X-Axis Travel | 8.45" |
Z-Axis Travel | 22.5" |
C Axis Spindle Rotation | Full C Axis |
Spindle Speeds | 0 - 4,000 RPM |
Spindle Nose / Bore / Bar Capacity | A2-6" / 3.0" / 2.5" |
Spindle Motor | 20 HP |
Spindle Torque | 120 ft/lbs |
Live Milling Speed | 4,000 RPM |
Number of Turret Positions | 12 Station Turret |
Rapid Traverse Rates | 710 IPM |
Tailstock Taper / Travel | MT #4 / 20" |
Machine Dimensions LxWxH | 126.5"x62"x72" |
Machine Weight | 9,000 lbs |
