2006 Haas VF-9/40
2006 Haas VF-9/40
Contact us for price
Location:Illinois
orCall (863) 439-6066
Description
Chip Auger
4th Axis Pre-Wired
Gearbox
Programmable Coolant Nozzle
Coordinate Rotation & Scaling
Visual Part Programming System
Spindle Orientation
User Definable Macros
Rigid Tapping
Remote Jog Handle
Specifications
| Manufacturer | Haas |
| Model | VF-9/40 |
| Year | 2006 |
| Condition | Used |
| Stock Number | 119834 |
| Table size | 84" x 36" |
| Table load capacity | 4,000 lbs. |
| X axis travel | 84" |
| Y axis travel | 40" |
| Z axis travel | 30" |
| Spindle nose to table top | 4" - 34" |
| Spindle speed | 8,100 RPM |
| Spindle taper | CAT 40 |
| Spindle motor-geared head | 30 HP |
| Transmission type | 2 Speed Geared |
| Tool magazine capacity | 40 Position ATC |
| Tool change time | 4.0 sec tool-tool |
| Rapid traverse rates | 700 IPM |
| Max. tool diam./length/weight | 3.5"/8"/12 lbs. |
| Machine dimensions | 183"x139"x129" |
| Machine weight | 25,000 lbs. |
