2023 Haas CL-1 Chucker Lathe w/ 8 Station Turret, 6 ft. Barfeeder, 5C Spindle Nose, 1" Bar Capacity, Rigid Tapping, ONLY 150 HOURS
2023 Haas CL-1 Chucker Lathe w/ 8 Station Turret, 6 ft. Barfeeder, 5C Spindle Nose, 1" Bar Capacity, Rigid Tapping, ONLY 150 HOURS
$43,500 (USD)
Location:Texas
or
Call (863) 439-6066
Description
6' Fully Integrated CL series Barfeeder
Parts Catcher
4" 3 Jaw Manual Scroll Chuck
8 Station Turret
Early Power Failure Detection Module
Memory Lock Key Switch
Spindle Orientation
Coolant System with Pump and 13 Gallon Tank
Rigid Tapping
1 GB Program Storage
Touch Screen Interface for Control
Media Display
Haas Drop
Haas Connect
Ethernet Interface
USB Port Interface
RS 232 Port Interface
Gang Style Tooling Kit
New Price as Equipped at over $58,000
Power On Hours: 2307
Servo On Hours: 220
Spindle Run Hours: 119 Hours
Specifications
| Manufacturer | Haas |
| Model | CL-1 |
| Year | 2023 |
| Condition | Used |
| Stock Number | 119949 |
| Chuck Size | 4" 3 Jaw Manual Scroll Chuck |
| Maximum Swing Over Cross Slide | 11" |
| Maximum Machining Diameter | 5" |
| Maximum Machining Length | 8" |
| X-Axis Travel | 12" |
| Z-Axis Travel | 8" |
| Spindle Speed | 6,000 RPM |
| Spindle Nose / Spindle Bore / Bar Capacity | 5C / 1.25" / 1" |
| Spindle Motor | 5 HP |
| Turret Type | 8 Station Turret |
| Machine Dimensions LxWxH | 78"x62"x70" |
| Machine Weight | 2,000 lbs |
